7. If you wish to use a BREAKPOINT (software break), specify the SH2A_SBSTK command to
enable use of a user stack before setting a PC break. While enabled, extra four bytes of a user
stack are used when a break occurs. The value of the stack pointer (R15) must be correctly set
in advance because a user stack is to be used. By default, use of a user stack is disabled. For
details on the command, refer to the help file.
• Example
To enable use of a user stack:
>SH2A_SBSTK enable
3.2.5 Notes on Setting the [Event Condition] Dialog Box and the BREAKCONDITION_
SET Command
1. When [Go to cursor], [Step In], [Step Over], or [Step Out] is selected, the settings of Event
Condition 3 are disabled.
2. When an Event Condition is satisfied, emulation may stop after two or more instructions have
been executed.
3.2.6 Performance Measurement Function
The emulator supports the performance measurement function.
1. Setting the performance measurement conditions
To set the performance measurement conditions, use the [Performance Analysis] dialog box or
the PERFORMANCE_SET command. When any line in the [Performance Analysis] window
is clicked with the right mouse button, a popup menu is displayed and the [Performance
Analysis] dialog box can be displayed by selecting [Setting].
Note: For the command line syntax, refer to the online help.
