Table 3.6 Registers and Values Set for the AUD Function
Pin Name of the
Port Function
AUD Function
Register and Bit to
be Set
Value to be Set
PB23 AUDCK PBCRH2[10:8] 3’b110
PB22 _AUDSYNC PBCRH2[10:8] 3’b110
PB24 AUDATA3 PBCRH2[10:8] 3’b110
PB25 AUDATA2 PBCRH2[10:8] 3’b110
PB26 AUDATA1 PBCRH2[10:8] 3’b110
PB27 AUDATA0 PBCRH2[10:8] 3’b110
Note that the AUD function can be used regardless of the above AUD pin settings in EV-chip unit
debugging mode.
10. Using the Watchdog Timer (WDT)
The WDT does not operate during a break.
11. Loading Sessions
Information in [JTAG clock] of the [Configuration] dialog box cannot be recovered by loading
sessions. Thus the TCK value will be 2.5 MHz.
