Table 2.4 Pin Assignments of the External Bus Trace Unit Connector (cont)
Pin
No.
I/O
(CONT)
E200F
Trace I/F
Connector
Pin Name
SH7211
Signal
Name
Voltage
Meaning of Signal
Note
104 IO UD-P51 IRQ3 3.3 V Interrupt Connect the IRQ3 signal of the MPU (fix IRQ3 to
high level when it is not used).
105 IO UD-P52 IRQ4 3.3 V Interrupt Connect the IRQ4 signal of the MPU (fix IRQ4 to
high level when it is not used).
106 IO UD-P53 IRQ5 3.3 V Interrupt Connect the IRQ5 signal of the MPU (fix IRQ5 to
high level when it is not used).
107 IO UD-P54 IRQ6 3.3 V Interrupt Connect the IRQ6 signal of the MPU (fix IRQ6 to
high level when it is not used).
108 IO UD-P55 IRQ7 3.3 V Interrupt Connect the IRQ7 signal of the MPU (fix IRQ7 to
high level when it is not used).
109 - GND GND GND
110 - GND GND GND
111 IO UD-P56 N.C -
112 IO UD-P57 N.C -
113 IO UD-P58 N.C -
114 IO UD-P59 N.C -
115 IO UD-P60 N.C -
116 IO UD-P61 N.C -
117 IO UD-P62 N.C -
118 IO UD-P63 N.C -
119 - GND GND GND
120 - GND GND GND
121 I UCONT-P0 _WE0/
_DQMLL
3.3 V Lowest-byte write
signal/lowest-byte
signals of SDRAM
(D7-D0)
Connect the _WE0 signal of the MPU
(necessary).
122 I UCONT-P1 _WE1/_WE/
_DQMLU
3.3 V Lower-byte write
signals/lower-byte
signals of SDRAM
(D15-D8)
Connect the _WE1 signal of the MPU
(necessary).
