25
Table 2.4 Pin Assignments of the External Bus Trace Unit Connector (cont)
Pin
No.
I/O
(CONT)
E200F
Trace I/F
Connector
Pin Name
SH7211
Signal
Name
Voltage
Meaning of Signal
Note
26 I UA-P21 A21 3.3 V Address bus Same as above.
27 I UA-P22 A22 3.3 V Address bus Same as above.
28 I UA-P23 A23 3.3 V Address bus Same as above.
29 - GND GND GND
30 - GND GND GND
31 I UA-P24 A24 3.3 V Address bus Connect the address signal of the MPU.
32 I UA-P25 A25 3.3 V Address bus Same as above.
33 I UA-P26 A26 3.3 V Address bus Same as above.
34 I UA-P27 A27 3.3 V Address bus Same as above.
35 I UA-P28 A28 3.3 V Address bus Same as above.
36 I UA-P29 A29 3.3 V Address bus Same as above.
37 I UA-P30 GND 3.3 V GND Input low level or connect GND.
38 I UA-P31 GND 3.3 V GND Input low level or connect GND.
39 - GND GND GND
40 - GND GND GND
41 IO UD-P0 D0 3.3 V Data bus Connect the data signal of the MPU.
42 IO UD-P1 D1 3.3 V Data bus Same as above.
43 IO UD-P2 D2 3.3 V Data bus Same as above.
44 IO UD-P3 D3 3.3 V Data bus Same as above.
45 IO UD-P4 D4 3.3 V Data bus Same as above.
46 IO UD-P5 D5 3.3 V Data bus Same as above.
47 IO UD-P6 D6 3.3 V Data bus Same as above.
48 IO UD-P7 D7 3.3 V Data bus Same as above.
49 - GND GND GND
50 - GND GND GND
51 IO UD-P8 D8 3.3 V Data bus Connect the data signal of the MPU.
52 IO UD-P9 D9 3.3 V Data bus Same as above.
53 IO UD-P10 D10 3.3 V Data bus Same as above.
