PCA4738xx-xxA User's Manual 1．Outline
R20UT0273EJ0200 Rev.2.00 Page 8 of 28
Oct 01, 2010
1
．
Outline
This product is a PROM programming adapter for the 38000 Series of Renesas 8-bit MCUs (available for some 740 Series
MCUs). The adapter is a tool that can be used to write programs into internal PROM of MCUs using a PROM programmer
commercially available. This chapter describes the package components, external views, system configuration and the
specifications of this product.
1.1 Package Components
This product package consists of the following items. When unpacking it, check to see if your product contains all of these
items. If there is any question or doubt about the packaged product, contact your local distributor.
Table 1.1 Contents
Contents
Main unit
PCA4738F-64A, PCA4738F-80A,
PCA4738F-100A, PCA4738S-64A
PCA4738G-100A,
PCA4738H-80A
PCA4738F-42A,
PCA4738S-42A
Interface unit PCA4738C PCA7402B PCA7402B
Connector
PCA4738D (28-pin)
PCA4738E (32-pin)
PCA7402D (28-pin)
PCA7402E (32-pin)
PCA7402E (32-pin)
User's Manual This manual
