PCA4738xx-xxA User's Manual 2．Usage (How to Write the Program)
R20UT0273EJ0200 Rev.2.00 Page 22 of 28
Oct 01, 2010
Table 2.8 List of programming areas and devices - 38000 Series (PCA4738E or PCA7402E connector)
MCU type name PROM programmer
MCU
Applicable MCU
ROM size
Device
Programming area
ROM area
of MCU
M38XXXE2 About 8 KB E080h--FFFDh E080h--FFFDh
M38XXXE3
Currently not available
About 12 KB D080h--FFFDh D080h--FFFDh
M38XXXE4 M38503E4
M38513E4
About 16 KB C080h--FFFDh C080h--FFFDh
M38XXXE5 Currently not available About 20 KB B080h--FFFDh B080h--FFFDh
M38XXXE6 M38504E6
M38514E6
About 24 KB A080h--FFFDh A080h--FFFDh
M38XXXE7 Currently not available About 28 KB 9080h--FFFDh 9080h--FFFDh
M38XXXE8 M38867E8 About 32 KB 8080h--FFFDh 8080h--FFFDh
M38XXXE9 Currently not available
About 36 KB 7080h--FFFDh 7080h--FFFDh
M38XXXEA M38184EA
M38197EA
About 40 KB 6080h--FFFDh 6080h--FFFDh
M38XXXEB Currently not available About 44 KB 5080h--FFFDh 5080h--FFFDh
M38XXXEC M38067EC
M38127EC
M38177EC
M38198EC
M38199EC
M38227EC
About 48 KB 4080h--FFFDh 4080h--FFFDh
M38XXXED Currently not available About 52 KB 3080h--FFFDh 3080h--FFFDh
M38XXXEE M38185EE
About 56 KB 2080h--FFFDh 2080h--FFFDh
M38XXXEF M38079EF
M38259EF
M3826AEF
M38749EF
About 60 KB
M5M27C101
1080h--FFFDh 1080h--FFFDh
Table 2.9 List of programming areas and devices - 75xx Group (PCA4738E or PCA7402E connector)
MCU type name PROM programmer
MCU
Applicable MCU
ROM size
Device
Programming area
ROM area
of MCU
M375XXE2
About 8 KB E080h--FFFDh E080h--FFFDh
M375XXE3
About 12 KB D080h--FFFDh D080h--FFFDh
M375XXE4
About 16 KB C080h--FFFDh C080h--FFFDh
M375XXE5
Currently not available
About 20 KB B080h--FFFDh B080h--FFFDh
M375XXE6 M37527E6 About 24 KB A080h--FFFDh A080h--FFFDh
M375XXE7
About 28 KB 9080h--FFFDh 9080h--FFFDh
M375XXE8
About 32 KB 8080h--FFFDh 8080h--FFFDh
M375XXE9
About 36 KB 7080h--FFFDh 7080h--FFFDh
M375XXEA
About 40 KB 6080h--FFFDh 6080h--FFFDh
M375XXEB
About 44 KB 5080h--FFFDh 5080h--FFFDh
M375XXEC
About 48 KB 4080h--FFFDh 4080h--FFFDh
M375XXED
About 52 KB 3080h--FFFDh 3080h--FFFDh
M375XXEE
Currently not available
About 56 KB 2080h--FFFDh 2080h--FFFDh
M375XXEF M37513EF
M37560EF
About 60 KB
M5M27C101
1080h--FFFDh 1080h--FFFDh
