User`s manual

PCA4738xx-xxA User's Manual 2．Usage (How to Write the Program)
R20UT0273EJ0200 Rev.2.00 Page 21 of 28
Oct 01, 2010
2.6 Setting the Programming Area
To write the program into an MCU, be sure to set the programming area. And also, specify its device of the PROM
programmer. The lists of programming areas and device are shown in Tables 2.6 to 2.9. Make note of the fact that the MCU
whose ROM is 32 KB or less has two devices applicable. For the MCUs not listed in Tables 2.6 to 2.9, refer to each MCU's
user's manual.
Table 2.6 List of programming areas and devices -38000 Series (PCA4738D or PCA7402D connector)
MCU type name PROM programmer
MCU
Applicable MCU
ROM size
Device Programming area
ROM area
of MCU
M38XXXE2 M38002E2
M38802E2
M38881E2
About 8 KB 6080h--7FFDh E080h--FFFDh
M38XXXE3 Currently not available About 12 KB 5080h--7FFDh D080h--FFFDh
M38XXXE4 M38002E4
M38022E4
M38073E4
M38112E4
M38203E4
M38223E4
M38813E4
M38903E4
About 16 KB 4080h--7FFDh C080h--FFFDh
M38XXXE5 M38102E5 About 20 KB 3080h--7FFDh B080h--FFFDh
M38XXXE6 M38063E6
M38123E6
M38254E6
About 24 KB 2080h--7FFDh A080h--FFFDh
M38XXXE7 Currently not available About 28 KB 1080h--7FFDh 9080h--FFFDh
M38XXXE8 M38004E8
M38027E8
M38067E8
M38184E8
M38207E8
M38257E8
M38267E8
About 32 KB
M5M27C256A
0080h--7FFDh 8080h--FFFDh
Table 2.7 List of programming areas and devices - 75xx Group (PCA4738D or PCA7402D connector)
MCU type name PROM programmer
MCU
Applicable MCU
ROM size
Device
Programming area
ROM area
of MCU
M375XXE2
About 8 KB 6080h--7FFDh E080h--FFFDh
M375XXE3 About 12 KB 5080h--7FFDh D080h--FFFDh
M375XXE4
Currently not available
About 16 KB 4080h--7FFDh C080h--FFFDh
M375XXE5 M37500E5 About 20 KB 3080h--7FFDh B080h--FFFDh
M375XXE6 M37510E6 About 24 KB 2080h--7FFDh A080h--FFFDh
M375XXE7 Currently not available About 28 KB 1080h--7FFDh 9080h--FFFDh
M375XXE8 M37500E8 About 32 KB
M5M27C256A
0080h--7FFDh 8080h--FFFDh
