2.5 Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 8.
10.5 21.5
Cable head
User system
Unit: mm
Tolerance: ±0.5 mm
IC socket
(NQPACK100SE
manufactured by
Tokyo Eletech Corporation)
Figure 8 Resulting Dimensions after Connecting User System Interface Cable
11
