2.4 Dimensions for User System Interface Cable Head

The dimensions for the user system interface cable head are shown in figure 7.

45.7

48.6

4.0

4-φ2.5

63.5

63.5

21.3

21.3

21.0

21.0

Unit: mm

Tolerance: ±0.5 mm

Figure 7 Dimensions for User System Interface Cable Head
