Section 1 Configuration
1
UTIONCA
Use an NQPACK100SE socket (manufactured by Tokyo
Eletech Corporation) for the TFP-100G package IC socket on
the user system.
Figure 1 shows the configuration of the HS2238ECN61H user system interface cable for the
TFP-100G package.
To emulator station
Cable body
Screws (M2 x 6 mm)
Socket cover
User system
IC socket
Cable head
Screws (M2 x 10 mm)
(for fastening cable head)
Figure 1 HS2238ECN61H User System Interface Cable
