8
2.3.2 Plugging the User System Interface Cable Body into the Emulator
Plug the cable body into the emulator, taking care to insert it straight, and push it firmly into place.
User system interface cable body
User system interface cable head
EXT1
EXT2
P
O
W
E
R
R
U
N
Emulator
User system interface cable
Figure 2.6 Plugging User System Interface Cable Body to Emulator
2.3.3 Plugging the User System Interface Cable Body into the Cable Head
Plug the cable body into the cable head on the user system.
2.4 Power Supply
2.4.1 AC Adapter
The AC adapter supplied with the emulator must be used at all times.
2.4.2 Polarity
Figure 2.7 shows the polarity of the power-supply plug.
5 V (outside)
GND (inside)
Figure 2.7 Polarity of Power Supply Plug
