218
Table G.1 GUI Menus (cont)
Menu
Option
Shortcut
Toolbar
Button
Remarks
View
(cont)
Gra-
phic
Image… Shift +
Ctrl + G
Opens the [Image] window.
Waveform… Shift +
Ctrl + V
Opens the [Waveform]
window.
Per-
form-
ance
Performance
Analysis
Shift +
Ctrl + P
Opens the [Performance
Analysis] window.
Debug Debug Sessions…
Opens the [Debug Sessions]
dialog box to list, add, or
remove the debug session.
Debug Settings…
Opens the [Debug Settings]
dialog box to set the
debugging conditions or
download modules.
Reset CPU
Resets the target hardware
and sets the PC to the reset
vector address.
Go F5
Starts executing the user
program at the current PC.
Reset Go Shift + F5
Resets the target hardware
and executes the user
program from the reset vector
address.
Go To Cursor
Starts executing the user
program at the current PC until
the PC reaches the address
indicated by the current text
cursor position.
Set PC To Cursor
Sets the PC to the address at
the row of the text cursor.
Run…
Launches the [Run Program]
dialog box allowing the user to
enter the PC or PC breakpoint
during executing the user
program.
Display PC Shift +
Ctrl + Y
Opens the Editor or
Disassembly window at the
address of the PC.
