(3) [Events] Sheet
Selecting the [Events] tab on the [Status] window displays this sheet.
Table 8.19 [Events] Sheet Item
[Item] Column [Status] Column
Resources Displays the resource information and the information on events such as
the breakpoint.
8.3.6 Extended Monitor Function
Selecting [View -> CPU -> Extended Monitor] or clicking the [Extended Monitor] toolbar button displays the
[Extended Monitor] window. This emulator displays the following items.
Table 8.20 [Extended Monitor] Window Items
[Item] Column [Value] Column
User Reset Displays the status of the reset pin.
User System Voltage Displays whether or not the user VCC is equal to or exceeds the value set in
[User VCC Threshold] on the [General] page of the [Configuration Properties]
dialog box.
User Cable Displays whether or not the user cable is connected.
Running status Displays the address bus value in the MCU and the status of the CPU while
the user program is running, and the cause of a break while the user program
is halted.
Break = <Cause of break>: Displays the cause of a break.
Address = <Address bus value>:
Displays the address bus value during the user program execution. While in
subactive mode, ‘(SubActive)’ is displayed after the address bus value.
Status = <Status of the CPU>: Displays the status of the CPU.
CPU: CPU instruction prefetch cycles or CPU data access cycles
MEDIUM: Medium-speed mode
SUB_ACTIVE: Subactive mode
SLEEP: Sleep mode
SUB_SLEEP: Subsleep mode
WATCH: Watch mode
STANDBY: Standby mode
Target Mode Displays the mode input from the user system.
Note: In this emulator, the update interval in the [Extended Monitor] window cannot be selected or changed.
