8.3.5 [Status] Window
Selecting [View -> CPU -> Status] or clicking the [Status Display] toolbar button displays the [Status] window.
The [Status] window has three sheets. This emulator displays the following items.
(1) [Memory] Sheet
Selecting the [Memory] tab on the [Status] window displays this sheet.
Table 8.17 [Memory] Sheet Items
[Item] Column [Status] Column
Target Device Configuration Displays memory mapping.
System Memory Resources Displays the memory resource of the emulator hardware.
Program Name Displays the program file name.
(2) [Platform] Sheet
Selecting the [Platform] tab on the [Status] window displays this sheet.
Table 8.18 [Platform] Sheet Items
[Item] Column [Status] Column
Connected To: Displays emulator name (driver used).
CPU Displays the target MCU name.
Mode Displays the selected mode.
Clock source Displays the selected clock.
Subclock source Displays the selected sub-clock.
Run status Displays the execution status.
Break: The user program breaks
Running: The user program is running
Cause of last break Displays the cause of the emulator stopped at a break. If a program
breaks in the sub-active state, '(SubActive)' will be displayed after the
cause of the break.
Ready: User program not executed (immediately after starting the High-
performance Embedded Workshop)
User Break: Break by the user
Software Break: Break by software breakpoint
On Chip Break B: Break by On Chip Break
Complex Event System: Break by complex event system
Stepping Completed: Break by stepping completed
Stepping Aborted: Break by stepping aborted
ROM Write Access Break: Break by writing to ROM
Write-protect Access Break: Break by writing to a read-only memory
Unused Area Access Break: Break by accessing to a guarded memory
Stack In I/O Area: Break by a stack in the I/O area
Invalid breakpoint: Break by a break instruction without Software Break
Event Time Count Displays the measured result of the timer between events.
Run Time Count Displays the total execution time of the program.
