Table 8.14 Environment for the H8/3867 E6000 Emulator CPU 300L Debugging Platform
Hardware [Device] Option [Clock] Option [SubClock] Option Expansion Hardware
HS3880EPI60H 0.5 MHz
1 MHz
2 MHz
Target/2
HS388REPI60H
H8/3862
H8/3863
H8/3864
H8/3865
H8/3866
H8/3867
H8/3822
H8/3823
H8/3824
H8/3825
H8/3826
H8/3827
0.5 MHz
2 MHz
Target/2
38.4 kHz
307.2 kHz
32.768 kHz
Target
None
Note: Target/2 in [Clock] and Target in [SubClock] are only available when the target system is connected.
Table 8.15 Environment for the H8/3887 E6000 Emulator CPU 300L Debugging Platform
Hardware [Device] Option [Clock] Option [SubClock] Option Expansion Hardware
HS3880EPI60H 0.5 MHz
1 MHz
2 MHz
Target/2
HS388REPI60H
H8/3882
H8/3883
H8/3884
H8/3885
H8/3886
H8/3887
H8/3842
H8/3843
H8/3844
H8/3845
H8/3846
H8/3847
0.5 MHz
2 MHz
Target/2
38.4 kHz
307.2 kHz
32.768 kHz
Target
None
Note: Target/2 in [Clock] and Target in [SubClock] are only available when the target system is connected.
Table 8.16 Environment for the H8/3937 E6000 Emulator CPU 300L Debugging Platform
Hardware [Device] Option [Clock] Option [SubClock] Option Expansion Hardware
HS388REPI60H H8/3935R
H8/3936R
H8/3937R
H8/3935
H8/3936
H8/3937
2 MHz
Target/2
Target
HS3937EIO60H or
HS3937REIO60H
Notes: 1. When Target/2 is selected in [Clock], a 5-MHz clock will be supplied from the expansion I/O board
(HS3937EIO60H or HS3937REIO60H).
2. Target in [SubClock] is only available when the target system is connected.
8.3.4 Memory Mapping Function
This function allows reserved (access-prohibited) areas to be specified in one-byte units. Each memory block can
be set in memory on the user system and the access can be specified as read-write, read-only, or access-
prohibited in each case. It is not possible to change the attributes of memory incorporated in the MCU (internal
ROM, internal RAM, or internal I/O).
