202
[General] page (cont)
[Break on access error] When this box is checked, a break (the user program stops) occurs if
your program accesses an access-prohibited area or writes to a write-
protected area.
[User VCC Threshold] Sets the voltage level for the user system. [Down] will be displayed in
[User System Voltage] of the [Extended Monitor] window when the actual
user VCC of the target system is lower than the specified value.
[User Signals] When this box is checked, the reset and NMI signals from the user
system are enabled.
[Driver] Displays the E6000 driver that is currently installed.
[Change driver in start up] When this box is checked, selection of a driver will be available next time
the emulator is connected.
The MCUs selectable by the [Device] option and options that depend on the MCUs are listed below. To emulate
an MCU with a description in the Expansion Hardware column, connect the correct expansion hardware.
Table 8.12 Environment for the H8/3827R E6000 Emulator CPU 300L Debugging Platform
Hardware [Device] Option [Clock] Option [SubClock] Option Expansion Hardware
HS388REPI60H H8/3822R
H8/3823R
H8/3824R
H8/3825R
H8/3826R
H8/3827R
0.5 MHz
2 MHz
8 MHz
Target/2
38.4 kHz
307.2 kHz
32.768 kHz
Target
None
Notes: 1. Target/2 in [Clock] and Target in [SubClock] are only available when the target system is connected.
2. To emulate an H8/3827S-group MCU, select an H8/3827R-group MCU as the [Device] option (e.g.
H8/3827R for emulation of the H8/3827S).
Table 8.13 Environment for the H8/3847R E6000 Emulator CPU 300L Debugging Platform
Hardware [Device] Option [Clock] Option [SubClock] Option Expansion Hardware
HS388REPI60H H8/3842R
H8/3843R
H8/3844R
H8/3845R
H8/3846R
H8/3847R
0.5 MHz
2 MHz
8 MHz
Target/2
38.4 kHz
307.2 kHz
32.768 kHz
Target
None
Notes: 1. Target/2 in [Clock] and Target in [SubClock] are only available when the target system is connected.
2. To emulate an H8/3847S-group MCU, select an H8/3847R-group MCU as the [Device] option (e.g.
H8/3847R for emulation of the H8/3847S).
