192
8.1.4 Memory Mapping Function
This function allows reserved (access-prohibited) areas to be specified in one-byte units. Each memory block can
be set in memory on the user system and the access can be specified as read-write, read-only, or access-
prohibited in each case. It is not possible to change the attributes of memory incorporated in the MCU (internal
ROM, internal RAM, or internal I/O).
8.1.5 [Status] Window
Selecting [View -> CPU -> Status] or clicking the [Status Display] toolbar button displays the [Status] window.
The [Status] window has three sheets. This emulator displays the following items.
(1) [Memory] Sheet
Selecting the [Memory] tab on the [Status] window displays this sheet.
Table 8.3 [Memory] Sheet Items
[Item] Column [Status] Column
Target Device Configuration Displays memory mapping.
System Memory Resources Displays the memory resource of the emulator hardware.
Program Name Displays the program file name.
