[General] page (cont)
[Break on access error] When this box is checked, a break (the user program stops) occurs if
your program accesses an access-prohibited area or writes to a write-
protected area.
[User VCC Threshold] Sets the voltage level for the user system. [Down] will be displayed in
[User System Voltage] of the [Extended Monitor] window when the actual
user VCC of the target system is lower than the specified value.
[User Signals] When this box is checked, the reset and NMI signals from the user
system are enabled.
[Driver] Displays the E6000 driver that is currently installed.
[Change driver in start up] When this box is checked, selection of a driver will be available next time
the emulator is connected.
The MCUs selectable by the [Device] option and options that depend on the MCUs are listed below. To emulate
an MCU with a description in the Expansion Hardware column, connect the correct expansion hardware.
Table 8.2 Environment for the H8/3800 E6000 Emulator CPU 300L Debugging Platform
[Device] Option [Clock] Option [SubClock] Option Expansion Hardware
H8/3802
H8/3801
H8/3800
H8/38024
H8/38023
H8/38022
H8/38021
H8/38020
H8/38004
H8/38003
0.5 MHz
2 MHz
8 MHz
Target/2
38.4 kHz
307.2 kHz
32.768 kHz
Target
None
Note: Target/2 in [Clock] and Target in [SubClock] are only available when the target system is connected.
