7.8.1 A/D Converter
Due to the use of a user system interface cable there is a slight degradation in the A/D resolution and above that
quoted in the hardware manual for the MCU being emulated.
7.8.2 Access to Unused Area
The unused area from H'FF80 to H'FF8F is used by the emulator system. Therefore, if this area is allocated to the
emulator by the MAP setting, the operation is not guaranteed. Do not use this area.
Do not access the register that is not used by the MCU with the emulator.
7.8.3 Program Execution by the Go Reset Command
When the program is executed using the Go Reset command, the E6000 emulator inputs a reset signal of
approximately 500 μs to the evaluation chip. This reset signal input time is added when the execution time
measurement result is displayed.
7.9 Handling Evaluation Chip Board (HS388REBK61H)
WARNING
1. Always switch OFF the emulator and user system before
connecting or disconnecting the evaluation chip board
(HS388REBK61H). Failure to do so will result in a FIRE HAZARD
and will damage the user system and the emulator product or
will result in PERSONAL INJURY. The USER PROGRAM will be
LOST.
2. Do not leave any object (such as metalic pieces) within the case
after removing the emulator cover. Otherwise this will result in a
FIRE HAZARD and will damage the user system and the emulator
product or will result in PERSONAL INJURY. The USER PROGRAM
will be LOST.
To remove/fasten the emulator cover and install the evaluation chip board (HS388REBK61H), take the
following steps.
1. Remove four screws from the sides of the emulator station.
2. Pull the emulator cover upward and remove it.
3. Insert connectors P1 and P2 of the evaluation chip board to the corresponding P1 and P2 of HS38000EPI61H.
Then fasten the two screws on the evaluation chip board to fix the board to the emulator.
4. Close the emulator cover and fasten it with the four screws.
