7.4 Handling Evaluation Chip Board (HS3800EBK61H)
WARNING
1. Always switch OFF the emulator and user system before
connecting or disconnecting the evaluation chip board
(HS3800EBK61H). Failure to do so will result in a FIRE HAZARD
and will damage the user system and the emulator product or
will result in PERSONAL INJURY. The USER PROGRAM will be
LOST.
2. Do not leave any object (such as metalic pieces) within the case
after removing the emulator cover. Otherwise this will result in a
FIRE HAZARD and will damage the user system and the emulator
product or will result in PERSONAL INJURY. The USER PROGRAM
will be LOST.
To remove/fasten the emulator cover and install the evaluation chip board (HS3800EBK61H), take the following
steps.
1. Remove four screws from the sides of the emulator station.
2. Pull the emulator cover upward and remove it.
3. Insert connectors P1 and P2 of the evaluation chip board to the corresponding P1 and P2 of HS38000EPI61H.
Then fasten the two screws on the evaluation chip board to fix the board to the emulator.
4. Close the emulator cover and fasten it with the four screws.
