AVcc and AVss:
AVcc
AVss
0.1 Fμ
27 k Ω
User system interface cable
Evaluation
chip
Figure 7.4 User System Interface Circuit for AVcc and AVss
CVcc and TEST:
When CVcc is connected to GND, or TEST is connected to Vcc level, a warning message is displayed at
initiation. Check the CVcc and TEST pins on the user system.
Evaluation
chip
TEST
CVcc
CVcc
TEST
Pin monitor circuit
CVcc
TEST
Vcc
Figure 7.5 User System Interface Circuit for CVcc and TEST
V0, V1, V2, and V3:
Evaluation
chip
User system interface cable
Figure 7.6 User System Interface Circuit for V0, V1, V2, and V3
