7.1.2 Operating Voltage and Frequency Specifications
Table 7.1 shows the MCU operating voltage and frequency specifications supported by the E6000 emulator. If
the emulator is used in an environment that exceeds the operating voltage range and operating frequency range
guaranteed for the MCU operation, normal emulator operation is not guaranteed. Note that the operation with
low voltage or high frequency is not supported in some MCUs.
Table 7.1 Operating Voltage and Frequency Specifications
No.
MCU Types
Operating Voltage (V)
Operating Frequency (φ)
(MHz)
1.8-5.5 1.0-2.0
2.7-5.5 1.0-5.0
1 H8/3802 group
H8/38024 group
4.5-5.5 1.0-8.0
2.2-3.6 1.0-2.0 2 H8/38004 group
2.7-3.6 1.0-5.0
NOTE
For details on the operating voltage and frequency specifications,
refer to the MCU hardware manual.
