Section 7 Hardware Specifications Specific to This Product
This section describes the hardware specifications on the H8/3800 E6000 and H8/388R E6000 emulators. There
are HS3800EPI60H, HS388REPI60H, and HS3880EPI60H that operate independently as the emulator, and
HS38000EPI61H, HS3800EBK61H, and HS388REBK61H that cannot work alone. In other words, only
HS3800EPI60H, HS3880EPI60H or HS388REPI60H can be used as an emulator to operate independently.
Otherwise, operation is only possible by a combination of HS38000EPI61H (common item) and the target
evaluation chip board suitable for the target MCU. Select one of the following five:
No. Emulator Name Independent Item Common Item Evaluation Chip Board
1 HS3800EPI60H ⎯ ⎯
2
H8/3800 E6000 emulator
⎯ HS38000EPI61H HS3800EBK61H
3 HS3880EPI60H ⎯ ⎯
4 HS388REPI60H ⎯ ⎯
5
H8/388R E6000 emulator
⎯ HS38000EPI61H HS388REBK61H
In sections 7 and 8, emulator names indicate the following items.
H8/3800 E6000 emulator: (a) HS3800EPI60H
(b) HS38000EPI61H + HS3800EBK61H
H8/388R E6000 emulator: (a) HS3880EPI60H
(b) HS388REPI60H
(c) HS38000EPI61H + HS388REBK61H
7.1 H8/3800 E6000 Emulator Specifications
The H8/3800 E6000 emulator supports the system development using the following microcomputers:
• H8/3802 group
• H8/38004 group
• H8/38024 group
7.1.1 Supported Items
See the development support tool catalog for the MCU type names and packages supported by the E6000
emulator and for the combination of the E6000 user system interface cables and optional boards.
