Chapter 6. Troubleshooting
6.1 Flowchart to Remedy the Troubles
Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated
until the emulator debugger starts up. Check this while the target system is disconnected. For the latest
FAQs visit the Renesas Tools Homepage.
http://www.renesas.com/eng/products/mpumcu/toolhp/faq/m16c80/m16c80_e.htm
Figure 6.1 Flowchart to remedy the troubles
Not normal
Normal
Not normal/Error displayed
Normal
Not normal/Error displayed
Normal
Turning on PC7501
Program window of emulator debugger displayed
1. Check the operating environment etc. of the emulator
debugger.
See the user's manual of the emulator debugger.
2. Reinstall the emulator debugger.
1. Check emulator system connections.
See, "3.7 Connecting the PC7501" (page 36).
2. Redownload the firmware.
See "4.2 Downloading Firmware" (page 50).
3. Restart the PC7501 system.
Error displayed
See "6.2 (4) Errors Occur at Debugger Startup (Target
Connected)" (page 69).
See "6.2 (3) EMEM Dialog Box is Not Displayed at Debugger
Startup (Target Not Connected)" (page 69).
Init dialog box of emulator
debugger displayed
Upper panel LED of PC7501
EMEM dialog box of emulator
debugger displayed
