Emulation Pod User's Manual
Table Of Contents
- Preface
- Contents
- 1. Precautions for Safety
- 2. Preparation
- 3. Setting Up
- 4. Usage
- 5. Specifications
- 6. Troubleshooting
- 6.1 Flowchart to Remedy the Troubles
- 6.2 When the Emulator Debugger Does Not Start Up Properly
- 6.3 Operation Differs from That of PROM Version MCUs
- (1) Does Not Operate with Operating Frequencies (3.6 V to 5.5 V) Properly
- (2) Does Not Operate with Operating Frequencies (2.7 V to 3.6 V) Properly
- (3) Cannot Reset from Target System
- (4) Data Values of ROM Area at Power-on Are Different
- (5) HOLD* control
- (6) A-D Conversion Values are Different from Expected Values
- (7) Outputs of ALE, Address and Others are Different from Those of Actual MCUs
- 7. Maintenance and Guarantee
( 3 / 78 )
Preface
The M30620T2-RPD-E is an emulation pod for the M16C/62 and M16C/62A Groups of 16-bit
microcomputers. It's used with a PC4701 emulator.
This user's manual mainly describes functions of the M30620T2-RPD-E emulation pod and how to
operate it. For details on the following products, which are used with M30620T2-RPD-E, refer to
each product's user's manual.
• Emulator: PC4701M/PC4701HS/PC4701L User's Manual
• Emulator debugger: M3T-PD30 User's Manual
All the components of this product are shown in "2.2 Package Components" (page 19) of this user's
manual. If there is any question or doubt about this product, contact your local distributor.
To use the product properly
Precautions for Safety
• In both this user's manual and on the product itself, several icons are used to insure
proper handling of this product and also to prevent injuries to you or other persons,
or damage to your properties.
• The icons' graphic images and meanings are given in "Chapter 1. Precautions for
Safety". Be sure to read this chapter before using the product.
When using outside Japan
• When using in Europe, the United States, or Canada, be sure to use both the emulator
(PC4701M, PC4701HS or PC4701L) and the emulation pod which meet overseas
standards. EMI standards are not met when the M30620T2-RPD-E is used with the
PC4700H or PC4700L emulator.
