Part Name Part Specification
Item No.
Description Part No.
Part Type Name
(Drawing No.,Product
Specification)
Manufacturer Name
Mounting
Direction
Required
Q’ty per
Unit
Supply
Classification
Remarks
17 Connector CN2 S2B-XH-A J.S.T. Mfg. Mounted directly 1
18 Connector CN1,3 S2B-XH-A J.S.T. Mfg. Not mounted 0
19 Connector CN4 TM2REA-1208 Hirose Mounted directly 1
20 Connector CN5 XM2C-0912 Omron Mounted directly 1
21 Connector CON1,2 FX1-144S-1.27DS Hirose Mounted directly 2
22 Connector XCN1 XG4C-1034 Omron Mounted directly 1
23 Jumper pin (2 pins) J5,7 FFC-2ASM1B Honda Tsushin Kogyo Jumper fixed 2
24 Jumper pin (2 pins) J3,8 FFC-2ASM1B Honda Tsushin Kogyo Not mounted 0
25 Jumper pin (3 pins) J4,9,10,11,12,13,14 FFC-3ASM1B Honda Tsushin Kogyo Mounted directly 7
26 Jumper pin (3 pins) J2,6,15,16,17 FFC-3ASM1B Honda Tsushin Kogyo Jumper fixed 5
27 Jumper pin (3 pins) H2 FFC-3ASM1B Honda Tsushin Kogyo Not mounted 0
28 Jumper pin (4 pins) J1 FFC-4ASM1B Honda Tsushin Kogyo Jumper fixed 1
29 LED LED1, L0,1,2,3 SML-211UT Rohm Mounted directly 5
30 LED L4,5,6,7 SML-211YT Rohm Mounted directly 4
31 Test pin TX2,3,4,16 ST-1-1 Mac-Eight Mounted directly 4
32 Test pin TX1,5,6,7,8,9,10,11, ST-1-1 Mac-Eight Not mounted 0
TX 12,13,14,15,17,18
Special note:
(1) Blank columns denote the same content as the upper row.
(2) If two or more part type names are written for one part, the upper row has priority.
(3) The asterisk (*) in the item No. column denotes that the rest is blank.
Special note:
PLL-M3A-2152G02 ( 2 / 4 )
REJ10B0224-0300/Rev.3.00 Jan. 2007 Page 71 of 82
