Renesas Solution Starter Kit for RX23W 6. Configuration
R20UT4446EG0102 Rev. 1.02 Page 33 of 41
Jun 22, 20
Table 6-21 below details the function of the jumpers associated with the USB Configuration.
Table 6-21: USB Configuration Jumper Option Links
Reference
Jumper Position
Configuration
Related Links
J4
Short Pin1-2
Self-powered
J5 (1-2 short), J3 (open)
Short Pin2-3
Bus-powered
J5 (1-2 short), J3 (2-3 short)
All open
DO NOT SET.
J5 (1-2 short)
J5
Short Pin1-2
USB0 Function mode
-
Short Pin2-3
USB0 Host mode
-
All open
DO NOT SET.
-
When using USB in function mode, be sure to set J5 to 1-2 Short. Also, do not plug in both USB0_1 and USB0_2
cables at the same time.
