6.10 LED Configuration
Table 6-11 below details the function of the option links associated with LED Configuration.
Table 6-11: LED Configuration Option Links
Signal name
MCU
MCU Peripheral Selection
Destination Selection
Pin
Port
Signal Fit DNF
Interface
/Function
Fit DNF
LED3 E10 P44 LED3
- -
LED3.K
-
-
P44
-
-
LED2 D9 P43 LED2
- -
LED2.K
-
-
P43
-
-
LED1 D8 P42 LED1
- -
LED1.K
-
-
P42
-
-
LED0 C8 P41 LED0
- -
LED0.K
-
-
P41
-
-
