User's Manual

6
WIRELESS INFORMATION
Wireless range:
This device has an open air line of sight transmission distance of 100
feet which complies with the Z-Wave standards. Performance can vary
depending on the amount of objects in between Z-Wave devices such
as walls and furniture. Every Z-Wave device set up in your house will
act as a signal repeater allowing devices to talk to each other and find
alternate routes in the case of a reception dead spot.
Radio frequency limitations:
1. Each wall or object (i.e.: refrigerator, bookshelf, large TV, etc) can
reduce the maximum range of 65 feet by up to 25 to 30%.
2. Plasterboard and wooden walls block less of the radio signal then
concrete, brick or tile walls which will have more of an effect on
signal strength.
3. Wall mounted Z-Wave devices will also suffer a loss of range as
they are housed in metal junction boxes which could reduce the
range by up to 25 to 30%.
TECHNICAL SPECIFICATIONS
Model no. BW8370US (ZXT-300US)
Model no. BW8370EU (ZXT-300EU)
RF Frequency 908.4MHz (US); ZXT-300US
RF Frequency 868.4MHz (EU); ZXT-300EU
IR Frequency Up to 455kHz
IR Learning Max 100 commands
Max. Range
up to 100ft outdoor line of sight, in
unobstructed environment
Power DC 5V 100mA
Humidity 10~85%, non-condensing
Dimension (LxWxT) 139 x 75 x 28.5 mm
Weight 90g
Control and Support Command Class
ZXT-300
Item Command Class Control Support
1
COMMAND_CLASS_CONFIGURATION No Yes
2
COMMAND_CLASS_CONFIGURATION_V2 No Yes
3
COMMAND_CLASS_VERSION No Yes
