User's Manual

Change Z-Wave-to-IR Channel (EP) on ZXT-300

Step Setup Key

LED Indication Status

on ZXT-300

Press and hold PROG button on

the ZXT-300 for 3seconds to

switch the EP (1->2->3->4-

>5->6->1->2...)

• LED flashes 1 = EP1

• LED flashes 2 = EP2

• LED flashes 3 = EP3

• LED flashes 4 = EP4

• LED flashes 5 = EP5

• LED flashes 6 = EP6

How to get the NIF “Node Information Frame” on ZXT-

300

Step Setup Key

LED Indication Status

on ZXT-300

ZXT-300 switch to Z-Wave-to-

IR Channel (EP1)

• LED flashes 1 times

then keep on

Press the PROG button on the

ZXT-300

(EP1 will response “NIF”

EP2, EP3, EP4, EP5, EP6 will

response “Multi-channel

capability report”)

• LED flashes 1 times

then keep on

(ZXT-300 will report the

supported command

class)

Reset ZXT-300 to factory default

Press and hold “PROG” button for 10seconds on ZXT-300. LED will

flashing until reset process is completed.
