Manual





T1. FX 1 Routing Button (Shift: Master Deck Assignment) [Traktor Pro]
T2. FX 2 Routing Button (Shift: Snap Mode) [Traktor Pro]
T3. FX 3 Routing Button (Shift: Quantize Mode) [Traktor Pro]
T4. FX 4 Routing Button (Shift: LFO Reset) [Traktor Pro]
T5. TRAX Encoder (Shift: Folder Navigation)
T6. Deck Assignment Buttons (Shift: Deck Cue)
T7. Dry/Wet Fine Adjustment (Shift: Effect Change in Advanced Effect Mode)
T8. Dry/Wet Fader (Shift: Headphones Volume)
T9. Effect Parameter <Advanced Effect Mode> respectively Dry/Wet Fine Adjustment (Shift:
Effect Change respectively Equalizer Kill Function) <Chained Effect Mode> [Traktor Pro]
T10. Effect Parameter <Advanced Effect Mode> respectivley Dry/Wet Fader <Chained Effect
Mode> [Traktor Pro] (Shift Equalizer Adjustment)
T11. FX On Button <Advanced Effect Mode> [Traktor Pro]
T12. Effect Reset <Advanced Effect Mode> respectively FX 1 On <Chained Effect Mode> [Traktor Pro]
T13. Effect Button 1 <Advanced Effect Mode> respectively FX 2 On <Chained Effect Mode> [Traktor Pro]
T14. Effect Button 2 <Advanced Effect Mode> respectively FX 3 On <Chained Effect Mode> [Traktor Pro]
T15. Loop Length [Traktor Pro] (Shift: Fine Pitch Controller)
T16. Loop Shift [Traktor Pro] (Shift: Tempo Bend Control)
T17. Filter (Shift: Cue Mix Fading)
T18. Pan (Balance) Control (Shift:Master Volume)
T19. Auto Loop Function (Shift: Loop In/Set Cue Button)
T20. Reloop Function [Traktor Pro] (Shift: Loop Out Button)
T21. Beat Jump Backward (Shift: Left-Sided GRID Shift)
T22. Beat Jump Forward (Shift: Right-Sided GRID Shift)
T23. Hot Cue Bank Select [Traktor Pro]
T24. Hot Cue Buttons [Traktor Pro]
T25. Hot Cue Save Button [Traktor Pro]
T26. Hot Cue Delete Button [Traktor Pro]
T27. Jog Wheel Mode Buttons
T28. Jog Wheel
T29. Shift Button
T30. Cup Button (Shift: ActCue Button [Traktor Pro])
T31. Cue Button (Shift: Select Next Cue Point [Traktor Pro])
T32. Play/Pause Button (Shift: Keylock)
T33. Sync Button (Shift: Tap Button)


B34. ON/OFF Button
B35 Kensington Lock
B36. Mains Connection (DC 6V/1.5A) (mains adapter optionally available)
B37. Mains Cord Strain Relief
B38. USB Port
