Manual



2
ENCODER/WHEEL
I/O FUNCTION
MIDI
CODE
CHANNEL+
MIDI CODE
FUNCTION CODE ACTION REMARK
0B BX
09H／49H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
1 I TRAX
09 9X 09H／49H(SHIFT ON)
7FH：ON／00H：OFF
0B BX
0AH／4AH(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
2 I FX SEL
09 9X 0AH／4AH(SHIFT ON)
7FH：ON／00H：OFF
0B BX
0BH／4BH(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
3 I FX 1 SEL
09 9X 0BH／4BH(SHIFT ON)
7FH：ON／00H：OFF
0B BX
0CH／4CH(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
4 I FX 2 SEL
09 9X 0CH／4CH(SHIFT ON)
7FH：ON／00H：OFF
0B BX
0DH／4DH(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
5 I FX 3 SEL
09 9X 0DH／4DH(SHIFT ON)
7FH：ON／00H：OFF
0B BX
16H／56H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
6 I -LENGTH+
09 9X 16H／56H(SHIFT ON)
7FH：ON／00H：OFF
0B BX
17H／57H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
7 I -MOVE+
09 9X 17H／57H(SHIFT ON)
7FH：ON／00H：OFF
2FH／6FH(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
FUNCTION OFF
30H／70H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
SCRATCH ON
31H／71H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
PITCHB ON
32H／72H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
SEARCH ON
0B BX
33H／73H(SHIFT ON) LEFT:40H-N／RIGHT:40H+N
TRAX ON
38H／78H(SHIFT ON) 7FH：ON／00H：OFF(RIGHT)
39H／79H(SHIFT ON) 7FH：ON／00H：OFF(LEFT)
SCRATCH ON
PLATTER NO TOUCH
2FH／6FH(SHIFT ON) 7FH：ON／00H：OFF
FUNCTION OFF
30H／70H(SHIFT ON) 7FH：ON／00H：OFF
SCRATCH ON
31H／71H(SHIFT ON) 7FH：ON／00H：OFF
PITCHB ON
32H／72H(SHIFT ON) 7FH：ON／00H：OFF
SEARCH ON
8 I WHEEL
09 9X
33H／73H(SHIFT ON) 7FH：ON／00H：OFF
TRAX ON
VR
I/O FUNCTION
MIDI
CODE
CHANNEL+
MIDI CODE
FUNCTION CODE ACTION REMARK
1 I DRY/WET 0B BX
29H／69H(SHIFT ON)
00H~7FH
2 I FX PARAM 1 0B BX
2AH／6AH(SHIFT ON)
00H~7FH
3 I FX PARAM 2 0B BX
2BH／6BH(SHIFT ON)
00H~7FH
4 I FX PARAM 3 0B BX
2CH／6CH(SHIFT ON)
00H~7FH
0B BX 00H~7FH
5 I FILTER
09 9X
2DH／6DH(SHIFT ON)
7F：CENTER IN／00：CENTER OUT
0B BX 00H~7FH
6 I PAN
09 9X
2EH／6EH(SHIFT ON)
7F：CENTER IN／00：CENTER OUT
3
KEY LED
I/O FUNCTION
MIDI CODE
CHANNEL+
MIDI CODE
FUNCTION CODE ACTION REMARK
1 O 1 09 9X
01H／41H(SHIFT ON) 7FH：ON／00H：OFF
2 O 2 09 9X
02H／42H(SHIFT ON) 7FH：ON／00H：OFF
3 O 3 09 9X
03H／43H(SHIFT ON) 7FH：ON／00H：OFF
4 O 4 09 9X
04H／44H(SHIFT ON) 7FH：ON／00H：OFF
5 O a 09 9X 05H (SHIFT ON)
7FH：ON／00H：OFF
6 O b 09 9X 06H (SHIFT ON)
7FH：ON／00H：OFF
7 O c 09 9X 07H (SHIFT ON)
7FH：ON／00H：OFF
8 O d 09 9X 08H (SHIFT ON)
7FH：ON／00H：OFF
9 O FX ON 09 9X
0EH／4EH(SHIFT ON) 7FH：ON／00H：OFF
10 O RST 09 9X
0FH／4FH(SHIFT ON) 7FH：ON／00H：OFF
11 O FX B1 09 9X
10H／50H(SHIFT ON) 7FH：ON／00H：OFF
12 O FX B2 09 9X
11H／51H(SHIFT ON) 7FH：ON／00H：OFF
13 O BEAT LOOP 09 9X
12H／52H(SHIFT ON) 7FH：ON／00H：OFF
14 O RELOOP 09 9X
13H／53H(SHIFT ON) 7FH：ON／00H：OFF
15 O < BEAT 09 9X
14H／54H(SHIFT ON) 7FH：ON／00H：OFF
16 O BEAT > 09 9X
15H／55H(SHIFT ON) 7FH：ON／00H：OFF
1AH／5AH(SHIFT ON) 7FH：ON／00H：OFF
1-4 ON
17 O 1/5 09 9X
34H／74H(SHIFT ON) 7FH：ON／00H：OFF
5-8 ON
1BH／5BH(SHIFT ON) 7FH：ON／00H：OFF
1-4 ON
18 O 2/6 09 9X
35H／75H(SHIFT ON) 7FH：ON／00H：OFF
5-8 ON
1CH／5CH(SHIFT ON) 7FH：ON／00H：OFF
1-4 ON
19 O 3/7 09 9X
36H／76H(SHIFT ON) 7FH：ON／00H：OFF
5-8 ON
1DH／5DH(SHIFT ON) 7FH：ON／00H：OFF
1-4 ON
20 O 4/8 09 9X
37H／77H(SHIFT ON) 7FH：ON／00H：OFF
5-8 ON
21 O CUP 09 9X
25H／65H(SHIFT ON) 7FH：ON／00H：OFF
22 O CUE 09 9X
26H／66H(SHIFT ON) 7FH：ON／00H：OFF
23 O PLAY 09 9X
27H／67H(SHIFT ON) 7FH：ON／00H：OFF
24 O SYNC 09 9X
28H／68H(SHIFT ON) 7FH：ON／00H：OFF
