Technical data

│
10
R
E
G
ULU
S
- R2B
C
stora
g
e water heaters - www.re
g
ulus.e
u
G 6/4” thread, nickel-plated copper
power output
(kW)
voltage
(V)
length L
(mm)
code
2 230 245 8935
3 230 305 8936
4.5 3 × 230 370 8937
6 3 × 230 495 8938
7.5 3 × 400 585 8939
9 3 × 400 680 8940
12 3 × 400 815 8941
G 6/4” thread, stainless steel, thermostatic head, adjustable by a knob
power output
(kW)
voltage
(V)
length L
(mm)
code
2 230 V 315 11783
3 230 V 350 11784
2 3 × 230 V 225 11787
3 3 × 230 V 285 11788
4.5 3 × 230 V 383 11789
6 3 × 400 V 478 11216
7.5 3 × 400 V 570 11215
9 3 × 400 V 665 11214
11.2 - Electric heating rods and a mounting flange for the inspection hole
Electric heating rods can be used in storage water heaters and in accumulation tanks. They can be power
supplied either by 230V or 3 × 230V/400V. Heating rods of output 2-12 kW can be installed into these tanks,
into the sleeves with G 6/4” inner thread (the right type should be selected with respect to its length and the
tank diameter). Electric heating rods are currently made of nickel-plated copper. They can be also supplied in
a copper or stainless-steel version. Heating rods with an integrated electronic thermostat and a safety thermo-
stat are also available.
Flange enabling installation of an electric heating rod into the lower inspection hole.
flange
diameter
flange thread code
170 mm
inner
G 6/4“
7376
L
75
100
L
100
