Technical data

15
ProScan 10T
With a resolution of 10.000 dpi, a dynamic
range of 3.9 Dmax and an extreme fast
scanning time of 7 Min. for a color scan with
10.000 dpi and 24 Bit color depth, reflecta
ProScan 10T provides top quality scans.
The high scanning speed and the hardware
based dust and scratch removal system
MAGIC TOUC contribute the scanner to a very
effective working tool. Using the attached
slide and film holder allows a high scan effi-
ciency and finally results in a time saving.
Technical data:
Filmtype: Negative and Positive as strip (35mm)
or slide (5x5cm),
Resolution: 10.000 dpi
Scan Area max.: 24,3 x 36,5 mm
Color Depth: 48 Bit
Dynamic Range: 3,9 Dmax
Image Sensor: Linea Color CCD
Lamp: Film saving LED
Scanning Time: 7 min. at 10.000 dpi and color depth
of 24 Bit (incl. Magic Touch)
Interface: USB 2.0
Dimension: 275x167x80 mm (L x W x H)
Includes:
Hardware: 1 x slide holder for 4slides with up to 3,2 mm
thickness, 1 x film holder for film strips with up to 6
images, Power Adaptor, USB-Cable, User Manual
Software: Scansoftware Cyberview, Adobe Photoshop
Elements 12; optional SilverFast Ai Studio
System requirements:
PC: XP, Vista (32 and. 64 Bit), 7 (32 and. 64Bit), 8
(32 and. 64 Bit), CPU: Intel P4 2 GHz or higher,
RAM: 1 GB Minimum, Free Hard Disk Space:
min. 10 GB
MAC: OS X 10.5+ or higher, CPU: Intel Core 2 Duo,
Speed 1.8 GHz, RAM: 1 GB, 667MHz,
DDR 2 SDRAM, PowerPC is not supported
Ref. No. 65450
