Technical data

PRODUCTS
14
Super 8 Scanner
With a resolution of 1920x1080 p (Full HD)
reflecta Super 8 Scanner allows your Super
8 films (5.78 x 4.01 mm) to digitize quickly
and easily. The scanner is connected to the
supplied power cable and connected via
USB cable to the PC. Then you have to
install the included software Cyberview and
clamp the roll of film onto the scanner.
Ready to go. The film will be transported
automatically and initially scanned frame
by frame.
Technical data:
Filmtype: Super 8 film (Positive or Monochrome
Film) 18 frames / sec + 24 frames / sec
Resolution: 1920 x 1080 p (Full HD)
or 1280 x 720p (HD)
Color Depth: 24 Bit
Scanning Time: 5,0 seconds / 2 pictures (about 2 hrs. 46
mins
for 15m Super 8 Film Reel)
Video File Size: 190 MB / 15 m Film (HD)
Scan Area: max. 5,79 x 4,01 mm (no 8mm film)
Filmtransport: automatic
Sensor: CMOS
Light Source: LED
PC Interface: USB 2.0
Film Format: AVI
Dimensions: 213 (L) x 143 (W) x 232 (H)
Max. film length: 180 m
Includes:
Hardware: USB Cable, Power Adapter, manual
Software: Scansoftware CyberView,
System requirements:
PC:Windows XP with SP2, Vista, 7, 8 (32 and. 64 Bit), CPU: Intel
P4 2 GHz or higher, RAM: 4 GB minimum, Hard disk free
space: min. 35 GB, Memory Requirement 15 m film / playing
time 3.5 min.: 3 GB
Ref. No. 66020
CrystalScan 7200 with ICE™
The ideal device for digitising your slides
and negatives with a high resolution.
The scanner offers 7200 or 3600 dpi to
allow for high-quality prints up to DIN A4
size and larger.
Technical data
Film type: Negatives and positives as strips (35 mm) or
slides (5x5 cm, up to 3.2 mm thick)
Manual loading
Opt. resolution: 7200 x 3600 dpi
Optical density: 3.2 Dmax
Colour depth: 48 bit
Image sensor: Linear colour CCD
Interface: USB 2.0
Includes
Hardware: Scanner, power adapter, USB cable,
User manual
Software: Scansoftware Cyberview X, Image Editing Pro-
gram; optional: Silverfast SE, Ai Studio
System requirements
PC: Pentium III or higher with min. 512 MB RAM,
Microsoft Windows XP/Vista/7/8
Mac: Apple Macintosh with USB port and 512 MB
RAM; Mac OS version 10.5 or higher
Ref. No: 65380 (CrystalScan 7200)
65380 + 65396 (CrystalScan 7200 + Silverfast SE)
