Technical data

11
x7-Scan
With the reflecta x7-Scan with 3200 dpi
resolution it´s possible to scan with 14,0
Megapixel and beside film and slide addi-
tionally pocketfilm (110)and 126 mm film.
The reflecta x7-Scan offers a 2,4“ LCD-
Display, an integrated SD/SDHC card slot
and a Lithium-Ion battery to allow using the
scanner completely independent from a PC
or power supply, respective as Stand-Alone
Scanner.
Technical data:
Filmtype: Negative and Positives as strip (35mm) or
slide (5x5cm), 110 mm (Pocket) film as
strips, 126 mm film as strips
Resolution: 3200 x 3200dpi at 14 Mio. Pixel
Display: 2,4 “ LCD-Display
Bright. Correction: via Button
Colour Depth: 30 Bit
Optical Density: 3.0 Dmax
Image Sensor: CMOS
Lamp: 3 white LEDs
Scan Speed: Fine Scan at 3200dpi: 2 Sec.
Max. scan range: 24,3 x 36,5 mm
PC Interface: USB 2.0 (not USB 1.1)
TV-Out (NTSC/PAL)
Mem. Card Slot: SD / SDHC
Battery Op. Time: approx. 2.5 hours or approx. 2,000 scans
Dimensions: 105 x 104 x 164 mm (L x W x H)
Includes:
Hardware: slide holder for 3 framed slides up to 3,2
mm thick, film holder for film strips up to 6
exposures, film holder for 110mm (Pocket)
film strips up to 8 exposures, film holder
126mm (instamatic) for film strips up to 7
exposures, USB-Cable, TV-Out Cable, AC
Adapter, Lithium-Ion Battery, Manual,
Cleaning Brush
Software: ArcSoft MediaImpression
(image editing program only)
Ref. No. 64370
x9-Scan
With a resolution of 5 megapixel and an
extremely fast scan time of 1 second for a
scan, the reflecta x9-Scan provides top
quality scans. The scanner is PC indepen-
dent, it´s not possible to scan via PC. Due
to the supplied lithium battery or AC adap-
ter, the scanner can be used anywhere. The
scanned images are stored on a SD/SDHC
card (not included) and can be viewed on
the 2.4” LCD Display immediately.
Technical data:
Filmtype: Negative and Positive as strip
(35mm) or slide (5x5cm)
Resolution: 1800 dpi
Scanning Time: 1 Second for 1 picture
Color Depth: 24 Bit
Sensor: CMOS
Lamp: 3 white LED
Scan Area max.: 24,3 x 36,5 mm
PC Interface: USB 2.0
Additional Interface: TV-Out (NTSC/PAL)
Display: 2,4“ TFT LCD Display
Focus: Fixfocus
EV adjustment: +- 2.0 EV
Color Balance: automatic
Card Slot: SD/SDHC up to 32 GB
Dimensions: 108x106x143 mm (Hx W x L)
System requirements
for software:
MAC: OS X 10.5+ or higher
PC: XP, Vista (32 u. 64 Bit), 7 (32 u. 64Bit),
8 (32 u. 64 Bit)
Includes:
Hardware: Slideholder for 3 Slides up to 3,2 mm
thickness, Filmholder for filmstrips up to 6
images, USB- and TV Out Cable, Lithium
Battery, AC Adaptor, User manual, Image
Editing program (MediaImpression 2)
Ref. No. 64290
