Owners manual

30160IN – 5JUN14 PCN3308 2014 CEQUENT™ PERFORMANCE PRODUCTS, INC PRINTED IN MEXICO
FOR KIT 30160
Figure 11: Pinning
Anchor Handles
Figure 9: Anchor Handles
in Unlocked Position
Figure 10: Anchor Handles
in Locked Position
8. If not already installed, the Left hand and Right hand torsion springs will need to be added to the center section.
The coil must face the rear of the truck and wide hook must sit over the casting as shown in Figure 12. Tighten
1/4-20 X 1 1/2 BOLT with 7/16 socket to 8 lb-ft.
Figure 12: Torsion Spring Assembly
Right Torsion Spring
Front of Truck
1/4-20 X 1 1/2 BOLT
Tube Spacer
Left Torsion Spring
Washer
6
Note: Handles can be turned
inward or outward to unlock hitch.
