Owners manual

30160IN – 5JUN14 PCN3308 2014 CEQUENT™ PERFORMANCE PRODUCTS, INC PRINTED IN MEXICO

FOR KIT 30160

1. Lubricate center section as shown in Figure 2 with lithium grease.

2. Lubricate pins (2) and slide bar opening as shown in Figure 3 with lithium grease prior to installation/operation.

3. Lubricate feet with lithium grease for easier engagement as shown in Figure 4.

Figure 3: Pin/Lubrication

Points (Bottom View)

Lubricate Pin

(Access through jaw opening)

Figure 2: Lubrication Points

Lubricate 6 places

Slide Bar Opening

LUBRICATION:

Figure 4: Lubrication Points

Lubricate feet

Typical on both Arches
