Owners manual

30160IN – 5JUN14 PCN3308 2014 CEQUENT™ PERFORMANCE PRODUCTS, INC PRINTED IN MEXICO
FOR KIT 30160
REF # QTY. DESCRIPTION
1 1 HEAD ASSEMBLY
2 1 CENTER SECTION
3 2 BASE ARCH
4 1 HANDLE TUBE
5 4 5/8-11 GR8 HEX HEAD BOLT
6 4 5/8 LOCK WASHER
7 2 1/4-20 GR2 HEX HEAD BOLT
8 2 TUBE SPACER
9 2 TORSION SPRING
10 2 3/8 CARRIAGE BOLT
11 2 3/8 NUT
12 2 3/8 LOCK WASHER
13 2 1/2” PULL PIN
14 2 SPRING RETAINING CLIP
REF # QTY DESCRIPTION
15 2 WASHER
16 1 HANG TAG
17 4 ANCHOR, BUSHING
18 4 ANCHOR, TEE PIN
19 2 HANDLE, LT ANCHOR
20 2 HANDLE, RT ANCHOR
21 4 LYNCH PIN
22 4 1” NUT
23 1 LABEL, WARNING
24 1 LABEL, OPERATING WARNING
25 1 LABEL, RATING
26 1 GRIP
27 1 COTTER PIN
Figure 33
1
2
3
4
5
6
7 8 9 15
10
11
12
17
18
19
21
16
26
20
13
14
27
24
25
23
