Owners manual

30160IN – 5JUN14 PCN3308 2014 CEQUENT™ PERFORMANCE PRODUCTS, INC PRINTED IN MEXICO

FOR KIT 30160

8. With:

•All trailer wheels still firmly blocked in front and behind each tire, and

•Truck stationary with the emergency brake on, and

•Trailer landing gear still resting on firm ground and supporting trailer weight; and

•Truck stationary and with emergency brake on:

Connect electrical cable between truck and trailer, connect breakaway switch cable from pin box to a permanent

part of truck, and raise tailgate of truck. Do not tow trailer until the Pull Test has been successfully completed.

7. Place bail pin through the bail pin holes in the handle and base plate to make sure the hitch jaw is locked closed. IF

FLAG BLOCKS HOLE FOR BAIL PIN, TRAILER HAS NOT BEEN PROPERLY CONNECTED TO HITCH. DO NOT

TOW! Repeat above steps until trailer is properly hitched. (see Figure 30)

6. With all trailer wheels still firmly blocked, landing gear still resting on firm ground and supporting trailer weight, and truck

stationary and in park with emergency brake on: visually check that bottom of pin box is resting on top of the hitch.

THERE SHOULD BE NO SPACE BETWEEN THESE SURFACES (see Figure 28). If space exists, (see Figure 29)

trailer has not been properly hitched. DO NOT TOW! Instead, repeat above steps until trailer is properly hitched. DO

NOT PLACE BODY UNDER TRAILER TO PERFORM THIS INSPECTION!

Figure 29

WRONG

Figure 28

CORRECT

High Pin

No Space

GAP

King Pin

Jaw closed

Figure 30

Hole for bail pin

Flag

Handle

Base plate

Bail pin placement

Bail Pin
