Series 30000 Electric Motor Driven Reels
Page 6
www.reelcraft.com
ITEM DESCRIPTION QTY.
EA33106 L12D EA33106 M12D EA33112 L10A EA33112 L12D EA33112 M10AX EA33112 M12D EA33112 M24D
1 Swivel assembly 1 S602026 S602026 S602026 S602026 S602026 S602026 S602026
2 Screw, 5/16-12 x 5/8” 9 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31
3 Side frame 2 260403 260403 260403 260403 260403 260403 260403
5 Nut, 5/16-18 8 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
6 Spool flange 2 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3
7 Snap ring 4 300007 300007 300007 300007 300007 300007 300007
8 Inlet assembly 1 600327-2 600327-2 600327-2 600327-2 600327-2 600327-2 600327-2
9 O-ring 1 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120
10 Screw, 5/16-18 x 3/4” 4 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51
11 Tie rod 4 260402-100 260402-100 260402-200 260402-200 260402-200 260402-200 260402-200
12 Spacer 4 260401-1 260401-1 260401-2 260401-2 260401-2 260401-2 260401-2
13 Hub & bushing assembly 3 S600640 S600640 S600640 S600640 S600640 S600640 S600640
15 Lock handle assembly 1 S280109 S280109 S280109 S280109 S280109 S280109 S280109
20 Screw, 5/16-18 x 1/2” 8 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51
21 Nut, 5/16-18 8 300107 300107 300107 300107 300107 300107 300107
22 Cross brace 2 261501-1 261501-1 261501-2 261501-2 261501-2 261501-2 261501-2
24 Screw, 1/4-20 x 5/8” 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
25 Drive motor 1 S260409 S260409 S260430 S260409 S260430 S260409 260450
26 Gear, motor 1 S260408 S260408 260434 S260408 260434 S260408 S260408
27 Screw 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-51 S2-52 S2-52
28 Bracket, motor 1 260405 260405 260456 260405 260456 260405 260405
29 Washer 4 300039 300039 300039 300039 300039 300039 300039
30 Screw 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-51 S2-52 S2-52
31 Flange nut 10-32 6 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3
32 Spool gear 1 260407 260407 260407 260407 260407 260407 260407
33 Spacer, gear 6 S260410 S260410 S260410 S260410 S260410 S260410 S260410
34 Lock nut 5/16-18 4 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
35 Chain, drive #35 1 S260406 S260406 S260406 S260406 S260406 S260406 S260406
36 Screw 10-31 x 1 1/8” 6 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112
ITEM DESCRIPTION QTY.
EA33118 L10A EA33118 L12D EA33118 M10AX EA33118 M12D EA33122 L12D EA33128 L12D EA33128 M12D
1 Swivel assembly 1 S602026 S602026 S602026 S602026 S602026 S602026 S602026
2 Screw, 5/16-12 x 5/8” 9 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31
3 Side frame 2 260403 260403 260403 260403 260403 260403 260403
5 Nut, 5/16-18 8 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
6 Spool flange 2 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3 S260399-3
7 Snap ring 4 300007 300007 300007 300007 300007 300007 300007
8 Inlet assembly 1 600327-2 600327-2 600327-2 600327-2 600327-2 600327-2 600327-2
9 O-ring 1 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120
10 Screw, 5/16-18 x 3/4” 4 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51
11 Tie rod 4 260402-300 260402-300 260402-300 260402-300 260402-400 260402-500 260402-500
12 Spacer 4 S260401-3 S260401-3 S260401-3 S260401-3 260401-4 260401-5 260401-5
13 Hub & bushing assembly 3 600640 600640 600640 600640 600640 600640 600640
15 Lock handle assembly 1 S280109 S280109 S280109 S280109 S280109 S280109 S280109
20 Screw, 5/16-18 x 1/2” 8 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51
21 Nut, 5/16-18 8 300107 300107 300107 300107 300107 300107 300107
22 Cross brace 2 261501-3 261501-3 261501-3 261501-3 261501-4 261501-5 261501-5
24 Screw, 1/4-20 x 5/8” 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
25 Drive motor 1 S260430 S260409 S260430 S260409 S260409 S260409 S260409
26 Gear, motor 1 260434 S260408 260434 S260408 S260408 S260408 S260408
27 Screw 5/16-18 x 5/8” 4 S2-52 S2-52 S2-51 S2-52 S2-52 S2-52 S2-52
28 Bracket, motor 1 260456 260405 260456 260405 260405 260405 260405
29 Washer 4 300039 300039 300039 300039 300039 300039 300039
30 Screw 5/16-18 x 5/8” 4 S2-52 S2-52 S2-51 S2-52 S2-52 S2-52 S2-52
31 Flange nut 10-32 6 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3
32 Spool gear 1 260407 260407 260407 260407 260407 260407 260407
33 Spacer, gear 6 S260410 S260410 S260410 S260410 S260410 S260410 S260410
34 Lock nut 5/16-18 4 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
35 Chain, drive #35 1 S260406 S260406 S260406 S260406 S260406 S260406 S260406
36 Screw 10-31 x 1 1/8” 6 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112
