Article DESCRIPTION Quantité
EA30106 L10A EA30112 L12D EA32106 L10A EA32106 L12D EA32106 M10A EA32106 M12D EA32112 L10A EA32112 L12D
1 Assemblage de pivot 1 -------- -------- 600888 600888 602033 602033 600888 600888
2 Vis, 5/16-12 x 5/8” 9 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31
3 Cadre Latéral 2 260403 260403 260403 260403 260403 260403 260403 260403
5 Écrou, 5/16-18 8 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
6 Tambour bridé 2 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3
7 Dispositif de retenue 4 300007 300007 300007 300007 300007 300007 300007 300007
8 Assemblage d’entrée 1 600327-2 600327-2 600327-1 600327-1 600327-1 600327-1 600327-1 600327-1
9 Anneau en “O” 1 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120
10 Vis, 5/16-18 x 3/4” 4 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51
11 Farre d’accouplement 4 260402-100 260402-200 260402-100 260402-100 260402-100 260402-100 260402-200 260402-200
12 Pièce d’espacement 4 260401-1 260401-2 260401-1 260401-1 260401-1 260401-1 260401-2 260401-2
13
Assemblage de moyeu et manchon
3 600640 600640 600640 600640 600640 600640 600640 600640
15
Assemblage de manche loquant
1 280109 280109 280109 280109 280109 280109 280109 280109
20 Vis, 5/16-18 x 1/2” 8 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51
21 Écrou, 5/16-18 8 300107 300107 300107 300107 300107 300107 300107 300107
22 Traverse 2 261501-1 261501-2 261501-1 261501-1 261501-1 261501-1 261501-2 261501-2
24 Vis, 1/4-20 x 5/8” 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
25 Moteur 1 260430 260409 260430 260409 260430 260409 260430 260409
26 Moteur à engrenages 1 260434 260408 260434 260408 260434 260408 260434 260408
27 Vis 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52
28 Support de moteur 1 260456 260405 260456 260405 260456 260405 260456 260405
29 Rondelle 4 300039 300039 300039 300039 300039 300039 300039 300039
30 Vis 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52
31 Écrou à embase 10-32 6 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3
32 Engrenages de tambour 1 260407 260407 260407 260407 260407 260407 260407 260407
33 Entretoise 6 260410 260410 260410 260410 260410 260410 260410 260410
34 Écrou à embase 5/16-18 4 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
35 Tambour bridé 1 260406 260406 260406 260406 260406 260406 260406 260406
36 Vis 10-31 x 1 1/8” 6 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112
www.reelcraft.com
Page 17
Article DESCRIPTION Quantité
EA32112 M12D EA32118 L12D EA32118 M12D EA32118 M24D EA32122 L12D EA32122 M12D EA32128 L12D EA32128 M12D
1 Assemblage de pivot 1 602033 600888 602033 602033 600888 602033 600888 602033
2 Vis, 5/16-12 x 5/8” 9 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31 S317-31
3 Cadre Latéral 2 260403 260403 260403 260403 260403 260403 260403 260403
5 Écrou, 5/16-18 8 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
6 Tambour bridé 2 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3 260399-3
7 Dispositif de retenue 4 300007 300007 300007 300007 300007 300007 300007 300007
8 Assemblage d’entrée 1 600327-1 600327-1 600327-1 600327-1 600327-1 600327-1 600327-1 600327-1
9 Anneau en “O” 1 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120 S211-120
10 Vis, 5/16-18 x 3/4” 4 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51 S7-51
11 Farre d’accouplement 4 260402-200 260402-300 260402-300 260402-300 260402-400 260402-400 260402-500 260402-500
12 Pièce d’espacement 4 260401-2 260401-3 260401-3 260401-3 260401-4 260401-4 260401-5 260401-5
13
Assemblage de moyeu et manchon
3 600640 600640 600640 600640 600640 600640 600640 600640
15
Assemblage de manche loquant
1 280109 280109 280109 280109 280109 280109 280109 280109
20 Vis, 5/16-18 x 1/2” 8 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51 S2-51
21 Écrou, 5/16-18 8 300107 300107 300107 300107 300107 300107 300107 300107
22 Traverse 2 261501-2 261501-3 261501-3 261501-3 261501-4 261501-4 261501-5 261501-5
24 Vis, 1/4-20 x 5/8” 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
25 Moteur 1 260409 260409 260409 260450 260409 260409 260409 260409
26 Moteur à engrenages 1 260408 260408 260408 260408 260408 260408 260408 260408
27 Vis 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52
28 Support de moteur 1 260405 260405 260405 260405 260405 260405 260405 260405
29 Rondelle 4 300039 300039 300039 300039 300039 300039 300039 300039
30 Vis 5/16-18 x 5/8” 4 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52 S2-52
31 Écrou à embase 10-32 6 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3 S79-3
32 Engrenages de tambour 1 260407 260407 260407 260407 260407 260407 260407 260407
33 Entretoise 6 260410 260410 260410 260410 260410 260410 260410 260410
34 Écrou à embase 5/16-18 4 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7 S85-7
35 Tambour bridé 1 260406 260406 260406 260406 260406 260406 260406 260406
36 Vis 10-31 x 1 1/8” 6 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112 S27-112
Série 30000 enrouleurs électriques
