3. Click on the “Get Configuration” button. It displays the currently
stored configuration parameters. These parameters can be ignored
for now.
4. Fill the values of the parameters
a. Channel: Channel number of the AP or Adhoc network that
the module should connect to. Refer tables Channel
Number Parameter (2.4 Ghz) and Channel Number
Parameter (5 Ghz).
b. Network Type
c. Security Mode- Security mode of the Access Point or Adhoc
network
d. uRate (refer table Data Rate Parameter)
e. Tx Power
f. Pre shared key- This can be left unfilled if the security
mode is “Open”.
g. SSID- This is the SSID of the Access Point or Adhoc
network to which the module should join
h. IBSS mode (Adhoc)
i. uChannel
j. DHCP Enable/Disable- Used in infrastructure mode
k. Source IP Address, Source Subnet Mask, Source Gateway
Address: If DHCP is disabled, an IP address, subnet mask
and gateway address should be entered for “Source IP
Address”, “Source Subnet Mask” and “Source Gateway”
respectively. The module will get configured with these
parameters.
l. Feature Bitmap- The decimal value of the parameter
feature_select_bitmap of the command Feature Select can
be entered here. It can be set to „0‟ for most use cases.
m. Auth mode- If “WEP” is selected in “Security Mode”, then
the options of “WEP Open” or “WEP Shared” should be used
here.
5. Click on the button “Set Configuration”. After the configuration is
successfully stored in the module, it sends an interrupt to the
Host. The Host should read the status in the same way as 17 and
should get the read value as 0x18. The configuration information
is stored in non-volatile memory of the module and can be
accessed by the Host at any time using the command “Get
Information about Stored Configuration”.
6. The module should now be power cycled or hard reset. The “Band”
command should be issued, after which the module will
automatically connect to the configured AP. Refer figure Wireless
Configuration Flow-SPI.
