4.9.10 Feature Select
Description
This command configures different sub-features in the WiFi module.
Relevance
This command is relevant both when the TCP/IP stack is enabled or bypassed.
Frame Body
typedef struct WiFi_CNFG_Feat_Sel {
UINT32 feat_sel_bitmap;
} WiFi_CNFG_Feat_Sel;
Structure Member
Name
Description
Feat_Sel_Bitmap
Bit[0] – Set to „0‟
Bit[1] – Set to „0‟
Bit[2]– „1‟ for WEP shared mode, „0‟
for WEP Open mode (stays at Open
mode by default)
Bit[3] – Set to „0‟ if the actual PSK
length of the AP is equal to or less
than 32 bytes. The length of the array
of the parameter uPSK in the
command “Join” should be 32 if this
bit is „0‟.
Set to „1‟ if the actual PSK length of
the AP is more than 32 bytes but
equal to or less than 63 bytes. The
length of the array of the parameter
uPSK in the command “Join” should be
64 if this bit is „1‟.
If this command is not issued, the
module accepts PSK length equal to or
less than 32 bytes. In such a case, the
length of the array of the parameter
uPSK in the command “Join” should be
32.
Bit[4:6] – Set to „0‟
Bit[7]- When set to „1‟, the
command “Get Information about
Stored Configuration” will return
three additional values- one is the
