Word
Management Frame
Descriptor
Data Frame Descriptor
Word4
W4[15:0]
If word0[7:0]=0xFF, then
W4[15:0] should be used for
specifying the length of
management frame body.
0x0000
Word5
W5 [15:0]
0x0000
0x0000
Word6
W6 [15:0]
0x0000
0x0000
Word7
W7 [15:0]
0x0004
0x0002
Table 12: Frame Descriptor for Management/Data Frames in SPI mode
NOTE: If the length stored in Word0 is 0xFF, then this is an indication that
the actual length is stored in Word4.
4.9 Management Frames (Frame Write)
The management frames represent the command frames that are sent from the
Host to the RS9110-N-11-2X module to configure the module for Wi-Fi access.
These are frame write commands. The following are the types of management
requests and responses and the corresponding codes. The first table is applicable
when the Host sends the frames to the module, the second table is applicable
when the module sends the frames to the host. The corresponding code is to be
filled in W0[15:8] mentioned in the table above.
Request Frame
Code
Band
0x18
Init
0x10
Scan
0x11
Join
0x12
Power mode
0x19
ffinst1 Upgrade
0X13
ffinst2 Upgrade
0X14
ffdata Upgrade
0X15
Sleep Timer
0x22
Query MAC and
network type
0x23
Feature Select
0x24
Enable store
configuration feature
0x2A
