CESSNA SECTION 6
MODEL 172R NAV III WEIGHT AND BALANCE/
GFC 700 AFCS EQUIPMENT LIST
U.S.
Figure 6-9 (Sheet 3)
ITEM NO EQUIPMENT LIST DESCRIPTION
REF
DRAWING
WT
LBS
ARM
INS.
26 - FIRE PROTECTION
26-01-S FIRE EXTINGUISHER 0501011-2 5.3* 43.0*
- FIRE EXTINGUISHER, HAND TYPE A352GS 4.8 44.0
- MOUNTING CLAMP AND HARDWARE 1290010-1 0.5 42.2
27 - FLIGHT CONTROLS
27-01-S DUAL CONTROLS, RIGHT SEAT 0506008-1 5.5* 12.4*
- CONTROL WHEEL, COPILOT 0513576-4 2.6 26.0
- RUDDER AND BRAKE PEDAL, COPILOT 0510402-16 1.1 6.8
27-02-A RUDDER PEDAL EXTENSION (SET OF 2)
(INSTALLED ARM SHOWN)
0501082-1 2.9 8.0
28 - FUEL
28-01-R AUXILIARY FUEL PUMP - 5100-00-4 0516015 1.9 9.5
28-02-R FUEL SENDER - 76-207-3 0522644 0.9 47.4
30 - ICE AND RAIN PROTECTION
30-01-S PITOT HEAT 0523080 0.1 28.0
31 - INDICATING/RECORDING SYSTEM
31-01-S RECORDING HOURMETER - C664503-0103 0506009 0.5 16.1
31-02-R PNEUMATIC STALL WARNING SYSTEM 0523112 0.4 28.5
31-03-R GEA 71 ENGINE/AIRFRAME UNIT 3930377 2.2 11.4
31-04-R GTP 59 OUTSIDE AIR TEMPERATURE (OAT)
PROBE
0518006 0.1 41.5
32 - LANDING GEAR
32-01-R WHEEL BRAKE AND TIRE, 6.00 X 6 MAIN (2) 0541200-7, -8 34.4* 57.8*
- WHEEL ASSY (EACH) C163001-0104 6.2 58.2
- BRAKE ASSY (EACH) C163030-0111 1.8 54.5
- TIRE, 4-PLY, 6.00 X 6, BLACKWALL (EACH) C262003-0101 7.9 58.2
- TUBE, (EACH) C262023-0102 1.3 58.2
32-02-R WHEEL AND TIRE ASSY, 5.00 X 5 NOSE 0543062-17 9.5* -6.8*
- WHEEL ASSY 1241156-12 3.5 -6.8
- TIRE, 6-PLY, 5.00 X 5, BLACKWALL C262003-0202 4.6 -6.8
- TUBE C262023-0101 1.4 -6.8
32-03-S WHEEL FAIRING AND INSTALLATION 0541225-1 16.5* 48.1*
- WHEEL FAIRING, NOSE 0543079-3 3.5 -3.5
- WHEEL FAIRINGS, MAIN (SET OF 2) 0541223-1, -2 10.1 61.1
- BRAKE FAIRINGS (SET OF 2) 0541224-1, -2 1.1 55.6
- MOUNTING PLATE (SET OF 2) 0541220-1, -2 0.8 59.5
172RPHBUS-00
6-21
