CESSNA SECTION 6
MODEL 172R NAV III WEIGHT AND BALANCE/
GFC 700 AFCS EQUIPMENT LIST
U.S.
Figure 6-9 (Sheet 1 of 6)
ITEM NO EQUIPMENT LIST DESCRIPTION
REF
DRAWING
WT
LBS
ARM
INS.
11 - PAINT AND PLACARDS
11-01-S PAINT, OVERALL WHITE WITH COLOR STRIPE 0500531 19.2* 95.4*
- OVERALL WHITE COLOR 18.4 91.5
- COLOR STRIPING 0.8 135.9
21 - AIR CONDITIONING
21-01-S VENTILATORS, ADJUSTABLE, CABIN AIR 0513575-2 1.7 60.0
21-02-S CABIN HEATER SYSTEM, SHROUDED MUFFLER
TYPE
0550365 2.5 -20.75
21-03-R FORWARD AVIONICS COOLING FAN - MC24B3 3930379 0.5 12.7
21-04-R AFT AVIONICS COOLING FAN 3940397 1.1 109.0
22 - AUTO FLIGHT
22-01-O GFC 700 AUTOPILOT 6.9 118.5
- PITCH SERVO 3940475 2.3 150.6
- PITCH TRIM SERVO 3940475 2.3 150.6
- ROLL SERVO 3940474 2.3 54.2
23 - COMMUNICATIONS
23-01-S STATIC DISCHARGE WICKS, (SET OF 10) 0501048-1 0.4 143.2
23-02-R AUDIO/INTERCOM/MARKER BEACON
- GMA 1347 AUDIO PANEL 320317 1.7 16.3
- CI-102 MARKER BEACON ANTENNA 3960188 0.5 129.0
23-03-R NAV/COM/GPS #1 COMPUTER 3921165
- GIA 63W INTEGRATED AVIONICS UNIT 3940397 4.9 113.3
- CI 2580-200 VHF COMM/GPS ANTENNA 3960220 0.5 61.2
23-04-S NAV/COM/GPS #2 COMPUTER 3921165
- GIA 63W INTEGRATED AVIONICS UNIT 3940397 4.9 113.3
- CI 2580-200 VHF COMM/GPS ANTENNA 3960220 0.5 61.2
- CI 420-10 XM ANTENNA 3960233 0.5 43.5
24 - ELECTRICAL POWER
24-01-R ALTERNATOR, 28 VOLT, 60 AMP, - 9910591-11 0550365 10.0 -29.0
24-02-R BATTERY, 24 VOLT, 8.0 AMP HOUR 0518034 23.2 -5.0
24-03-R POWER DISTRIBUTION MODULE - S3100-366 0518034 6.4* -2.5*
- ALTERNATOR CONTROL UNIT - AC2101 53100-366 0.2 -2.5
- MASTER CONTACTOR - X61-0007 53100-366 0.7 -2.5
- STARTER CONTACTOR - X61-0027 53100-366 0.7 -2.5
- AMMETER TRANSDUCER - CS3200 53100-366 0.1 -2.0
24-04-S BATTERY, STANDBY - AVT 200413 0518025 14.0 11.2
172RPHBUS-00
6-19
