Version 1.4.0 SVN 29352 BETA

50 50

4. When desired selection is made, press the MENU button to set.

TOUCHSCREEN

1. Press and hold the desired parameter to gain access to advanced setting adjustments.

2. Press the field - a keypad type menu may appear to allow adjustments.

3. Press the desired parameter settings to adjust.

4. When desired selection is made, press anywhere in the screen area to set and exit the advanced

settings submenu.
