Version 1.4.0 SVN 29352 BETA

BOMB EVF

Figure 12: BOMB EVF

Focus Ring

EVF User Key 1 / 2

EVF Tally Light

x Focus Ring: Adjusts optimal subject focus for your eye. Available diopter range is +2.0 to -5.0.

x EVF User Key 1: Initiates user defined camera function. Default: 1:1 Magnify

x EVF User Key 2: Initiates user defined camera function. Default: False Color : Exposure
