User Manual

28
Line 2
Actual Setpoint
Access
P
D
dISP
LOCS
F1
F2
P
D
Pro
NO
Pro
dISP
LOCS
Ln2
Pid
SP
Ln2
LOC
Line 2
Setpoint 1
Access
SP1
Ln2
LOC
Line 2
Setpoint 2
Access
SP2
Ln2
LOC
Line 2
Output Power
Access
OP
Ln2
LOC
Line 2
Deviation
Access
dEv
Ln2
LOC
Line 2
SP Ramping
Access
SPrP
Ln2
LOC
Line 2
Actual PID
Access
Pid
Ln2
LOC
ACt
Line 2
Primary PID
Access
Pid
Ln2
LOC
Pri
Line 2
Alternate PID
Access
Pid
Ln2
LOC
ALt
display parameTers: line 2 parameTer value aCCess - pid (Pid)
LINE 2 ACTIVE SETPOINT VALUE
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the active setpoint value
can be adjusted in the selected display loop by using the ! and @
keys while viewing SP. When configured for d-ENt, the P key must
be pressed to select the item prior to changing the value.
LINE 2 SETPOINT 1 VALUE
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Setpoint 1 value can
be adjusted in the selected display loop by using the ! and @ keys
while viewing SP1. When configured for dEnt, the P key must be
pressed to select the item prior to changing the value.
LINE 2 SETPOINT 2 VALUE
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Setpoint 2 value can
be adjusted in the selected display loop by using the ! and @ keys
while viewing SP2. When configured for dEnt, the P key must be
pressed to select the item prior to changing the value.
LINE 2 OUTPUT POWER VALUE
LOC drEd dEnt PrEd PEnt HrEd HEnt
Displays the Output Power value on Line 2 in the selected display
loop. In manual mode, the value can be adjusted in the selected
display loop by using the F1 and F2 keys. When configured for dEnt,
the P key must be pressed to select the item prior to changing the
value.
LINE 2 DEVIATION VALUE
LOC drEd PrEd HrEd
Displays the difference between Temp/Process and the Actual
Setpoint value on Line 2 in the selected display loop.
LINE 2 SETPOINT RAMPING VALUE
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Setpoint Ramping
value can be adjusted in the selected display loop by using the ! and
@ keys while viewing SPrP. When configured for dEnt, the P key
must be pressed to select the item prior to changing the value.
LINE 2 ACTUAL PID VALUES
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Actual PID values (P,
I & D) can be adjusted in the selected display loop by using the !
and @ keys while viewing the selected parameter. When configured
for dEnt, the P key must be pressed to select the item prior to
changing the value.
LINE 2 PRIMARY PID VALUES
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Primary PID values (P,
I & D) can be adjusted in the selected display loop by using the !
and @ keys while viewing the selected parameter. When configured
for dEnt, the P key must be pressed to select the item prior to
changing the value.
LINE 2 ALTERNATE PID VALUES
LOC drEd dEnt PrEd PEnt HrEd HEnt
When configured for dEnt, PEnt or HEnt, the Alternate PID values
(P, I & D) can be adjusted in the selected display loop by using the
! and @ keys while viewing the selected parameter. When
configured for dEnt, the P key must be pressed to select the item prior
to changing the value.
SP
Ln2
LOC
SP1
Ln2
LOC
SP2
Ln2
LOC
OP
Ln2
LOC
dEv
Ln2
LOC
SPrP
Ln2
LOC
Pid
Ln2
LOC
ACt
Pid
Ln2
LOC
Pri
Pid
Ln2
LOC
ALt
